BTG12030
For enhanced productivity, it’s possible to load new workpieces on one side of the machine while machining occurs on the other, provided safety protocols are strictly followed
Product Details
Various Auto-Change head attachments. Designed for stability, the moving parts experience minimal and uniform wear, contributing to the machine’s longevity and sustained accuracy over time.
Technical Specifications
| Parameter Category | BTG 4025 | BTG 6025 | BTG 6030 | BTG 8030 | BTG 12030 |
|---|---|---|---|---|---|
| Travel (X/Y/Z)/mm | 4200*2500*1200 | 6200*2500*1200 | 6200*3000*1200 | 8200*3000*1200 | 12200*3000*1200 |
| Table size (mm) | 4000*2100 | 6000*2100 | 6000*2600 | 8000*2600 | 12000*2600 |
| Max feeding height | 1500mm (can be customized) | 1500mm (can be customized) | 1500mm (can be customized) | 1500mm (can be customized) | 1500mm (can be customized) |
| Spindle taper | BT50 | BT50 | BT50 | BT50 | BT50 |
| Spindle power | 28/42KW 268/401NM (gearbox 1070/1604NM) | 28/42KW 268/401NM (gearbox 1070/1604NM) | 28/42KW 268/401NM (gearbox 1070/1604NM) | 28/42KW 268/401NM (gearbox 1070/1604NM) | 28/42KW 268/401NM (gearbox 1070/1604NM) |
| Spindle RPM | 8000rpm (Belt) / Gearbox 6000rpm (op) | 8000rpm (Belt) / Gearbox 6000rpm (op) | 8000rpm (Belt) / Gearbox 6000rpm (op) | 8000rpm (Belt) / Gearbox 6000rpm (op) | 8000rpm (Belt) / Gearbox 6000rpm (op) |
| Rapid feed rate (X/Y/Z) | 20/20/20 M/min | 20/20/20 M/min | 20/20/20 M/min | 20/20/20 M/min | 20/20/20 M/min |
| Max feeding Width (mm) | 3160 | 3160 | 3600 | 3600 | 3600 |
| Machine weight (Tom) | 42 | 52 | 58 | 70 | 115 |
| Machine size mm | 7500*6100*4000 | 9500*6100*4000 | 9500*6600*4000 | 11500*6600*4000 | 15500*6600*4000 |
| Control system | SIEMENS 828D / 840D | SIEMENS 828D / 840D | SIEMENS 828D / 840D | SIEMENS 828D / 840D | SIEMENS 828D / 840D |
Product Advantages
The machine’s moving components are engineered to minimize impact changes, ensuring long-term precision even after extended use.
Company Strength
High-precision and high-speed mold machining performance
Our BTG series delivers exceptional precision and speed for complex mold manufacturing applications.
Our machine is capable of achieving five-face machining
Our machine is capable of achieving five-face machining for complex workpieces in a single setup.
Freight Information
This machine will be loaded into 6×40 feet OT (open top) containers for international shipping.
Our preventive maintenance service includes different rebuilding / overhauling and retrofitting options so that technological or economic obsolescence can be put off for as long as possible.
